After seeing that ASUS has made accessible its new WiFi 7 routers sequence, I acquired very excited and acquired the BE3600, which I suppose is an entry-level machine, though the worth undoubtedly said in any other case. That was with the expectation that it does help the 6GHz radio. However, the field says one thing else and so does the {hardware}, so bear in mind that roughly 250$ is not going to provide the 6GHz radio and you might be higher off getting a WiFi 7 entry level.

Anyway, after the preliminary betrayal, I made a decision to open up the case of the router and, as typical, I checked the areas beneath the silicone ft. And certainly, there are 4 screws there, however ASUS simply had so as to add a Guarantee Seal didn’t they?

In fact, if it’s not plastic nicks and scuffs, there’s all the time the choice responsible a small piece of glued piece of plastic. And it principally breaks at contact, so you aren’t allowed to place your little paws there. In any other case, you danger dropping the guarantee. Within the US, this seal shouldn’t be even there because it seems to not be enforceable, however within the EU, ASUS doesn’t appear to truly care.

After getting the screws out, I checked if there’s a fifth one beneath the massive label and there wasn’t, so I took a prying device and tried to detach the higher facet of the router. It was weirdly inflexible and that’s often an indication that I could have missed a screw. Let’s examine below the label once more, this time in its entirety. However no, there isn’t any different screw, so I simply needed to push tougher. This does imply some further plastic marks, so bye bye guarantee, however a minimum of I lastly managed to take away the highest facet.

We will see the small PCB within the center, however what’s with these handles? It’s simply wasted house for some bizarre design choice. This router might have been much more compact. Properly, let’s transfer ahead and detach the 4 antennas. Don’t fear, there isn’t any glue and none are soldered, so it’s pretty straightforward to take them out. Then, the PCB could be indifferent as effectively and we will see that on either side there are some warmth spreaders. These should be eliminated, so I took out the screws from the underside facet, releasing the 2 massive warmth spreaders.

There may be an aluminum cowl on the underside facet, however there’s nothing of curiosity for us beneath it. There’s additionally a soldered chip which I assumed was for storage, however I discovered the chipset on the opposite facet, so no concept what’s beneath it. I additionally took the final remaining screws and the entrance facet revealed all its aluminum covers. Let’s take away them. Watch out as a result of ASUS put them too tightly and one did get deformed. Once more, bye bye guarantee. OK, now let’s get a very good take a look at the primary chipsets.

That’s about all for this teardown article. I used to be removed from impressed by this router, however I’ll check it regardless, so ensure to examine again when you’re to see the outcomes I get.
